种类与概述/Brief Introduction：

全自然轴向柱塞泵泵式膏体酱装灌机我是你司利用专业市场需要开拓的新企业产品。该机型选取SUS304304不绣钢轴向柱塞泵泵式的计量泵履行装灌，且集自然上盖、自然旋盖、组合件组合件为一起，实惠实用性强，征占平数小，宽泛利用于药厂、物品、药剂、化工品、化装品等制造行业的气体包装袋，符合标准GMP规则规范。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

显著特点/characteristic：

◆应用液压泵式记量泵制定灌装线，适合几种黏黏度液态物质，导致精度较高；泵的架构应用快接式替换系统，方便刷洗、紫外线灯消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆注塞泵式检定泵汽缸环金属质量据产业及药液含量的多种用于硅硅橡胶，四氟丁二烯或同一金属质量，特俗商务活动用于瓷质金属质量。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC操作装置，变頻调节，主动化程度较高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不灌装设备，自然计数法功效。Lack of bottle filling, automatic counting function◆装量优化方便简洁，可是一次优化所有的计算泵的充填量，也可造成有几个计算泵实现微幅优化；操控用简，优化很快。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆包装针头设置有防渗漏系统设计，充填时潜进瓶底包装，比较慢回落，制止泡沫。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆整体可应用差异规模的罐子，调准便利，可在暂时性间内完工。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆主机按GMP规定设计方案。The machine designed according to the requirements of GMP

技术水平基本参数/technic parameter：

适用于塑料瓶子尺寸Size of bottles	20-1000ml（据让生产厂家）20-1000 - ml (according to your need）
可用于小瓶内径Apply the bottle diameter	¢20-¢150mm
用于盖子年纪Apply the lid specifications	¢20-¢70mm
制造程度 production capacity	四头装灌：1000-2500瓶/h Four filling head: 1000-2500 bottles per hour 八头装灌：2500-4000瓶/一小时 Eight head filling: 2500-4000 bottles per hour 12头灌装设备：4000-6000瓶/几小时 12 head filling: 4000-6000 bottles per hour
装量偏差The load error	±1%
旋盖符合标准率Screw cover percent of pass	≥99%
24v电源power supply	380V，50HZ
公率power	3.0KW
安全阀gas sources	0.4-0.75MPA
加速度有效控制speed control	变频器调压variable speed
